XP-3318II thiết bị đo khí dễ cháy cầm tay New Cosmos
XP-3318II là thiết bị đo khí dễ cháy cầm tay New Cosmos hiện đang được HandHeld phân phối tại thị trường Việt Nam, ứng dụng trong hầu hết lĩnh vực…

New Cosmos Việt Nam
XP-3318II XP-3368II and XP-3368II-W portable multi gas detector
Đặc trưng
- Chuyển đổi sang 32 loại nồng độ khí*
- Thiết kế mạnh mẽ
- Mô hình phạm vi rộng
- Có thể thiết lập tối đa năm loại khí dễ cháy làm khí mục tiêu (tùy chọn)
- Nguồn điện có thể lựa chọn: pin AA kiềm / pin AA niken kim loại hydride có thể sạc lại
- Chức năng hẹn giờ và bấm giờ
- Xây dựng trong đèn pin
*Chỉ dành cho XP-3318II và XP-3368II-W
Model | XP-3368II-W | XP-3368II | XP-3318II | |||
---|---|---|---|---|---|---|
Target Gas | Combustible gas | Oxygen | Combustible gas | Oxygen | Combustible gas | Oxygen |
/solvent vapor | /solvent vapor | /solvent vapor | ||||
Detection Principle | Catalytic | Galvanic cell | Catalytic | Galvanic cell | Catalytic | Galvanic cell |
Mesuring Range | 0.0–100.0%LEL (100.1–110.0%LEL) | 0–25vol% | 0–5000ppm or | 0–25vol% | 0–100%LEL | 0–25vol% |
(Reference Indication) | Enable to display in ppm. | (25.1–50.0vol%) | 0–10000ppm | (25.1–50.0vol%) | (100.1–110.0%LEL) | (25.1–50.0vol%) |
(5001–5500ppm or 10001–11000ppm) | ||||||
Accuracy*2 | ≤ 1000ppm : ±100ppm | ±0.3vol% | ≤10%F.S. : ±2.5%F.S. | ±0.3vol% | ±5%F.S. | ±0.3vol% |
1001ppm<n≤10000ppm : ±500ppm | >10%F.S. : ±5%F.S. | |||||
Other than above: ±5%F.S. | ||||||
Resolution | 0.1%LEL or 1ppm | 0.1vol% | 1ppm | 0.1vol% | 0.1%LEL | 0.1vol% |
Alarm Set Value | 20%LEL | 18vol% | 250ppm or 500ppm | 18vol% | 20%LEL | 18vol% |
Response Time | T90: 30 seconds | ー | T90 : 30 seconds | ー | T90 : 30 seconds | ー |
Continuous Operation Time*3 | Approx. 15 hours | |||||
Sampling Method | Extractive | |||||
Alarm Method | Gas Alarm: Beeping with flashing red light and AL icon on the LCD Divice Alarm: Beeping with flashing yellow light and error message on the LCD |
|||||
Power Source | ・Non-rechargeable alkaline AA battery x4: Toshiba LR6, Panasonic LR6X, Duracell MN1500, Energizer E91 or Varta 4106 ・Rechargeable nickel metal hydride AA battery x4: New Cosmos HR-3UTG |
|||||
Operating Temperature/Humidity | -20 to 50℃ 95%RH. No condensation | |||||
Compliance*1 | ATEX: Ex II 1G Ex ia da IIC T4 Ga*1 IECEx: Ex ia da IIC T4 Ga*1 CE (ATEX, EMC, RoHS, RE nad LVD directives) |
|||||
Ingress Protection | IP67 | |||||
Main Features | Self-diagnosis (sensor error), Zero adjustment, Battery level indication, Flashlight, Peak-hold, LCD backlight, Audio alarm muting during gas alarm, Time indication, Alarm test, Alarm volume change, Audio muting | |||||
Dimensions | W91 x H164 x D44mm | |||||
Mass | Approx. 460g (including batteries) | |||||
Accessaries | Gas sampling tube(1m), Shoulder strap, Drain filter, Filter element, Alkaline AA batteries(or Rechargeable nickel metal hydride AA batteries) x 4, Screen protector film x 3 |
